how to display 256 color bmp files in trubo c++ 3.0??? i ve already displayed a 16 color bitmap in turbo c++...
i came across this code but it doesnt work...pls tell me whts the error...

#include<iostream.h>
#include<graphics.h>
#include<fstream.h>
#include<conio.h>
struct A{
    char type[2];                 /* Magic identifier            */
    unsigned long size;                       /* File size in bytes          */
    unsigned short int reserved1, reserved2;
    unsigned long offset;                     /* Offset to image data, bytes */
}HEADER,HEADER1;
struct B{
    unsigned long size;               /* Header size in bytes      */
    unsigned long width,height;                /* Width and height of image */
    unsigned short int planes;       /* Number of colour planes   */
    unsigned short int bits;         /* Bits per pixel            */
    unsigned long compression;        /* Compression type          */
    unsigned long imagesize;          /* Image size in bytes       */
    unsigned long xresolution,yresolution;     /* Pixels per meter          */
    unsigned long ncolours;           /* Number of colours         */
    unsigned long importantcolours;   /* Important colours         */
}INFOHEADER,INFOHEADER1;

huge DetectSvga()
{
    return 2;
}

void Show()
{
    fstream File;
    File.open("c:\\tc\\bin\\tet.bmp",ios::in);
    char Ch;
    File.read((char*)&HEADER,14); //This is the header part of the Bitmap.
    File.read((char*)&INFOHEADER,40); //This is another part of the bitmap
    unsigned int i;
    char ColorBytes[4];
    char*PaletteData;

    PaletteData=new char[256*3];

    if(PaletteData)//if memory allocated successfully
    {
	//read color data
	for(i=0;i<256;i++)
	{
	    //pls xplain wht this part does..i don understand it fully
	    File.read(ColorBytes,4);
	    PaletteData[(int)(i*3+2)]=ColorBytes[0]>>2;
	    PaletteData[(int)(i*3+1)]=ColorBytes[1]>>2;
	    PaletteData[(int)(i*3+0)]=ColorBytes[2]>>2;
	}

	outp(0x03c8,0);      //tell DAC that data is coming

	for(i=0;i<256*3;i++) //send data to SVGA DAC
	{
	    outp(0x03c9,PaletteData[i]);
	}
	delete[]PaletteData;
    }

    for(i=0;i<INFOHEADER.height;i++)       //This for loop is used to display the bitmap.
    {
	for(int j=0;j<INFOHEADER.width;)
	{
	    File.read(&Ch,1); // Here Ch reads the color of your bitmap.
	    putpixel(0+(j++),0+INFOHEADER.height-i-1,Ch);

	}
    }

    File.close();

}
void Show1()
{

    char Ch;
    fstream File;
    File.open("c:\\tc\\bin\\ab.bmp",ios::in);
    File.seekg(54,ios::beg);
    File.seekg(256*4,ios::cur);
    for(int i=0;i<214;i++)
    {
	for(int j=0;j<356;j++)
	{
	    File.read(&Ch,1); //Here Ch is the character which reads the color of your bitmap.
	    putpixel(10+j,10+39+i,Ch);
	}
    }
}
void main()
{
clrscr();
    int gd = DETECT, md, a;
    initgraph(&gd,&md,"c:\\tc\\bgi"); //Path may be different in your computer.
    installuserdriver("svga256",&DetectSvga);
Show();
  getch();
setcolor(BLACK);
setfillstyle(1,0);
bar(0,0,640,480);//clears the screen..cant use clrscr() as den myscreen turns grey
   Show1();
   getch();

}

PS-
1. i have svga256.bgi in c:\\tc\\bgi...do i need sum other files??
2. this is to be used in my skool project...n i asked my teacher n she said u cant use allegero,fastgraph or ne other compiler...i HAVE to use turbo c++ onli<sigh>
3."ab.bmp"(file i m trying to open) is attached with this msg
4.when i try to run the code...if i use show(),i get a completely destroyed form of the pic...its worse thn wht i get by displaying 16 colors... if i use show1(),i get the same output but this tym its inverted also...pls help!!!!!!!!!

Try installing the lib folder again... from some other copy...Its a common problem in TC...you wont have that problem again once you replace that folder with the proper ones.

Or get a real compiler!!!!

> this is to be used in my skool project...n i asked my teacher n she said u cant use allegero,fastgraph or ne other compiler
Scratch that, get a real teacher instead.
They don't know C any better than you do. They "learnt" some tricks for TurboC 20 years ago, and are now too scared to update to another compiler because all that they know is in fact useless.

Which in turn means that all that YOU will know will in fact be useless.

commented: Agreed! +16
Member Avatar for skandh

hey...thnk u sooo much...all ur replies were really helpful specially the last one..but one more thing...is using dev c++ REALLY THT simple???
fr eg- for loading a bmp file,is dere ne command lyk

loadbitmap(x_cord,y_cord,filename);

???

Member Avatar for skandh

***this is fr other CBSE guys who have the same problem***

i just solved the prob...i successfully displayed 256 color bitmap in turbo C++ 3.0....i m so tempted to post the code but its against the rules...so i cant :(
but ill c if i cn upload the code in snippets section...
btw, i used mode13h n bitmap headers..google fr it...

Member Avatar for skandh

but one small prob....the size i get is 320x200...i noe deres no way i cn get 640x480 in mode13h...so the prob remains...still cant get 640x320x256 in turbo c++ 3.0...

Member Avatar for skandh

o wow!! u r so funi!!!!!!

commented: Go and dribble on some other forum -7

The problem is that the palet is BGRA

B = Blue
G = Green
R = Red
A = Reserved (not used)

so each color in the palet has 4 bytes.

Member Avatar for skandh

i managed to get it "almost" right...now i cn display the bmp clearly in 1024x768 or 640x420...but the bmp is tiled...cant spot the prob..

#include<iostream.h>
#include<conio.h>
#include<graphics.h>
#include<fstream.h>
#include<stdio.h>
struct A{
    char type[2];                 /* Magic identifier            */
    unsigned long size;                       /* File size in bytes          */
    unsigned short int reserved1, reserved2;
    unsigned long offset;                     /* Offset to image data, bytes */
};

A HEADER;

struct B{
    unsigned long size;               /* Header size in bytes      */
    unsigned long width,height;                /* Width and height of image */
    unsigned short int planes;       /* Number of colour planes   */
    unsigned short int bits;         /* Bits per pixel            */
    unsigned long compression;        /* Compression type          */
    unsigned long imagesize;          /* Image size in bytes       */
    unsigned long xresolution,yresolution;     /* Pixels per meter          */
    unsigned long ncolours;           /* Number of colours         */
    unsigned long importantcolours;   /* Important colours         */
};
B INFOHEADER;
void Show();
huge DetectSvga()
{
    return 4;// 4 for 1024x768,2 for 640x480
}
void main()
{
    int gdriver = DETECT,gmode;
    installuserdriver("SVGA256",&DetectSvga);
    initgraph(&gdriver,&gmode,"c:\\tc\\bgi"); //Path may be different in your computer.
    getch();
    Show();
    getch();
}
void Show()
{
    fstream File;

    File.open("c:\\tc\\bin\\bri1.bmp",ios::in);

    unsigned char Ch;

    File.read((char*)&HEADER,14);
    File.read((char*)&INFOHEADER,40);

    unsigned int i;
    char ColorBytes[4];
    char*PaletteData;

    PaletteData=new char[256*3];

    if(PaletteData)//if memory allocated successfully
    {
	//read color data
	for(i=0;i<256;i++)
	{
	    File.read(ColorBytes,4);
	    PaletteData[(int)(i*3+2)]=ColorBytes[0]>>2;
	    PaletteData[(int)(i*3+1)]=ColorBytes[1]>>2;
	    PaletteData[(int)(i*3+0)]=ColorBytes[2]>>2;
	}

	outp(0x03c8,0);      //tell DAC that data is coming

	for(i=0;i<256*3;i++) //send data to SVGA DAC
	{
	    outp(0x03c9,PaletteData[i]);
	}
	delete[]PaletteData;
    }
    for(i=0;i<INFOHEADER.height;i++)       //This for loop is used to display the bitmap.
    {
	for(int j=0;j<INFOHEADER.width;j++)
	{
	    File.read(&Ch,1); // Here Ch reads the color of bitmap.
	    putpixel(100+j,100+INFOHEADER.height-i-1,Ch); //puts the bmp at 100,100

	}
    }

    File.close();
}

bri1.bmp is attached

.....

commented: Worst post of the day award! -6
Member Avatar for skandh

k..finally figured out the mistake..this is the correct code...
this code can display 256 color bitmap in 640x480 or 1024x768

#include<iostream.h>
#include<conio.h>
#include<graphics.h>
#include<fstream.h>
#include<stdio.h>
struct A
{
char type[2];                 /* Magic identifier            */
unsigned long size;                       /* File size in bytes          */
unsigned short int reserved1, reserved2;
unsigned long offset;                     /* Offset to image data, bytes */
}HEADER;
struct B
{
unsigned long size;               /* Header size in bytes      */
unsigned long width,height;                /* Width and height of image */
unsigned short int planes;       /* Number of colour planes   */
unsigned short int bits;         /* Bits per pixel            */
unsigned long compression;        /* Compression type          */
unsigned long imagesize;          /* Image size in bytes       */
unsigned long xresolution,yresolution;     /* Pixels per meter          */
unsigned long ncolours;           /* Number of colours         */
unsigned long importantcolours;   /* Important colours         */
}INFOHEADER;
void loadbitmap(int x,int y,char filename[8])
{
fstream File;
File.open(filename,ios::in);
unsigned char Ch;
File.read((char*)&HEADER,14);
File.read((char*)&INFOHEADER,40);
unsigned int i;
char ColorBytes[4];
char*PaletteData;
PaletteData=new char[256*3];
if(PaletteData)//if memory allocated successfully
{
for(i=0;i<256;i++)
{
File.read(ColorBytes,4);
PaletteData[(int)(i*3+2)]=ColorBytes[0]>>2;
PaletteData[(int)(i*3+1)]=ColorBytes[1]>>2;
PaletteData[(int)(i*3+0)]=ColorBytes[2]>>2;
}
outp(0x03c8,0);      //tell DAC that data is coming
for(i=0;i<256*3;i++) //send data to SVGA DAC
{
outp(0x03c9,PaletteData[i]);
}
delete[]PaletteData;
}
for(i=0;i<INFOHEADER.height;i++)
{
for(int j=0;j<INFOHEADER.width;j++)
{
File.read(&Ch,1); // Here Ch reads the color ofbitmap
putpixel(x+j,y+INFOHEADER.height-i-1,Ch); //puts the bmp at x,y
}
}
File.close();
}
int huge DetectSvga()
{
return 4;// 4 for 1024x768,2 for 640x480
}
void main()
{
int gdriver = DETECT,gmode;
installuserdriver("SVGA256",&DetectSvga);
initgraph(&gdriver,&gmode,"c:\\tc\\bgi"); //path maybe diff. in your comp.
char a[8]="mm3.bmp";//this file should be placed in TC\BIN
loadbitmap(100,200,a);
getch();
}

some imp. things-
1.ALL the images should be first converted into 256 color bitmap using micosoft paint.
2.make sure that the image dimensions are divisible by 4...for eg-340x288 picture will work but a 342x289 picture wont work.
3.you need svga256.bgi to run this prog...i cant attach this file as the extension is nt supported...heres the link-
http://www.filefactory.com/file/ah8f7h6/n/svga256_bgi
...copy that file into TC\BGI
4.incase your computer is not able to run this prog. ,your comp. does not have correct drivers installed..
5.if u have any doubts,mail to - <snip>

skandh.

commented: N.A -3

Nothing is happening ... the code is worthless. and you should use cleardevice() instead of drawing a bar

Skand this correct verison is doing the job but half downward image is turns out to be hazy...where is the prob

commented: A one year bump of easily the worst thread I have ever seen on this website. -1

hey... what is DAC and '>>2' in d palette data reading.. plz tell me how the palette data is read and what is d port in d outp function(0x03c9)???????????
